Features

This MCU (microcontroller) leaf is intended for evaluating image processing and edge AI applications, and for developing STM32N6 firmware.

AP05 STM32N6 uses STMicroelectronics’ STM32N6 series, based on Arm Cortex-M55.

The schematic, PCB layout, and KiCad project are available in the Documents section below. Detailed Leafony specifications and pin assignment descriptions will be added once confirmed.

Main Use Cases

Evaluation of image processing and edge AI applications with camera input
Development and verification of STM32N6 firmware
Prototyping with a high-performance MCU leaf on the Leafony Bus

Public Specifications

Item	Description
MCU	STM32N6 series
CPU	Arm Cortex-M55
Use cases	Image processing, edge AI, graphics
Development	STM32CubeIDE / STM32CubeN6
Interfaces	Leafony Bus, USB Type-C, external connectors

Development Environment

Use STM32CubeN6 and STM32CubeIDE provided by STMicroelectronics for STM32N6 software development.

Documents

Design files are available in the AP05 STM32N6 GitHub repository.

Revision History

September 19, 2026: Added links to the schematic, PCB layout, and KiCad project
May 2026: Added AP05 STM32N6 page
